162W 54x3W Outdoor Linear Wall Washer Light

RS-WW54*3W-C, 162W, 110-240V,IP65 RGB DMX city color wall washer led lighting


  • item no.:

    RS-WW162W-C
  • payment:

    T/T, WESTERN UNION, PAYPAL
  • product origin:

    China
  • color:

    Single color/RGB DMX
  • shipping port:

    Shenzhen
  • lead time:

    7-10
product details

   LED wall washer is also called Outdoor LED Wall Washer, LED Wall washer light, led city color, led wall washer light, etc.

All of them with with high LM famous brand & Edison high power led. The led wall wash light Working Voltage: DC36V, AC110-230V

Constant current driver, No flash, fast response to achieve over-current, use of safty.

RGB DMX512(1990 standard) and RDM system. No waterproof glue to seal the light, IP65 waterproof structure.

Easy maintain and replace freely.

   DMX decoder built inside, can be made with plug to plug connection. To make sure of high quality for the internal control

LED Wall Washer Light, we use rubble cable.



Specifications of 162W Outdoor Led Restaurant Wall Washer Lighting:


 Item Number

 RS-WW162W-C

 Input Voltage

 DC36V, AC110-230V

 Input Current

 3.5A

 Driver place

 Internal driver and DMX decoder

 Output Power

 162W

 Luminous Flux Output

 80-90LM/W Epistar, 90-100LM/W for high LM famous brand

 Rendering Index

 >70Ra(white color)

 Body size

 W97.5*H95.5*L1000mm  (H181mm with bracket)

 Beam angle

 10-90degree or 15*80 / 10*45degree (confirm with client)

 Light source

 High power 3W Epistar LED / High LM famous brand LED

 Operating temperature

 -35~ +45 Degrees Celsius

 Storage temperature

 -30~ +65 Degrees Celsius

 Color optional

 White(2700-6500K) / Red / Yellow / Green / Blue / RGB

 Housing material

 6063 Aluminum

 LED’s Operating Life

 ≥45,000Hours

 IP rate

 IP65

 Cable wire

 1 meter 2core / 3core / 4core female-male cable

 RGB Control way

 Auto color change / DMX512 controllable


Features of 162W Outdoor Led Restaurant Wall Washer Lighting

1.     High quality die-casting Aluminum light body, be oxidized beauty and good heat dispersing performance.

        Private mold for all lamp housing.

2.     Sealing up the tempered glass with silicone gaskets to reach IP65 waterproof rate. No waterproof glue

        inside of lamp. You can replace PCB with led freely once problem happened.

3.     Using super-brightness and high power led chips. Built-in constant voltage power supply driver .

4.     PMMA optical lens. with beam angle 8 -90 degrees. Achieve different floor requests.

5.     Working voltage is: DC 36V or AC110V-240V.

6.     Single color with steady-on; Auto-control color change synchronously .DMX512 controllable system.

7.     Long life, up to 45,000 hours.



Applications for 162W Outdoor Led Restaurant Wall Washer Lighting

Apply to Building, indoor or outdoor lights, Flooding for the landscape structure to outstanding building character. Hotels, airport, Metro. etc
